Malossi ALUMIN-CYL. KIT 47,6 pin 12 H2O MHR

CYLINDER KIT MHR

TECHNICAL FEATURES

CYLINDER

• Material: special aluminium alloy with high percentage of silicon and titanium that guarantees exceptional strain strength even at high temperatures.
• Heat treatment: special quenching and stabilizing treatment that gives the material increased toughness and strength, guaranteeing that mechanical and size specifications will remain unaltered for temperatures of up to 250 °C.
• Chip-forming machining: carried out on NC machining centres with extremely-limited size and shape tolerance (roundness, perpendicularity).
• Inner surface coating: effected using silicon carbide on a nickel matrix with heat treatment that guarantees extreme hardness (around 600 HVO, 1/5) and excellent resistance to wear.
• Internal machining of cylinder: using special machines that allow a degree of finish on the cylinder barrel walls whose roughness corresponds with the angles set at the design stage (grinding process using special stone).
• Port and exhaust diagrams: designed and manufactured especially for racing. The definition of the port and exhaust diagrams has requested considerable effort on the part of our engineers both on engine test stands and the circuits on which the trophy is held.

PISTON

• Material: special aluminium alloy with a very high percentage of silicon and titanium that guarantees both excellent heat resistance and strain strength upon temperature variation.
• External coating: graphite coating that guarantees a very low friction coefficient
• Structure: reinforced in order to offer resistance to the stress suffered by cylinder units used for top-level competition, but at the same time light enough to reduce inertial force.
• Ring: 1 mm nodular-cast-iron single ring with rectangular cross section and hard-chromium coating on outer surface.

PISTON RINGS

• Rings in very strong modular cast iron with ground, wear-resistant, hard chrome metal-spray coating on the contact surface.

HEAD

• Material: special alluminium alloy with a very high heat exchange coefficient.
• Geometry of heat exchange surfaces recalculated and increased.
• Combustion chamber completely-designed to obtain a high compression ratio with a very high turbolece.
• Machining: numerically controlled machines.

Modellek:

• APRILIA SR (carb.) 50 2T LC 2004-> (PIAGGIO) (IT IS ADVISED TO USE crankshaft 53 7600)
• APRILIA SR R 50 2T LC euro 4 2018-> (PIAGGIO CA81M) (IT IS ADVISED TO USE crankshaft 53 7600 - For the proper installation of the cylinder kit it is necessary to fit the temperature sensor ADAPTER, art. 1518132B)
• APRILIA SR R (carb.) 50 2T LC (PIAGGIO) (IT IS ADVISED TO USE crankshaft 53 7600)
• APRILIA SR Street 50 2T LC euro 2 (IT IS ADVISED TO USE crankshaft 53 7600)
• DERBI GP1 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• DERBI GP1 OPEN 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• DERBI GP1 REVOLUTION 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• GILERA DNA 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• GILERA RUNNER SP 50 2T LC <-2005 (IT IS ADVISED TO USE crankshaft 53 7600)
• GILERA RUNNER SP 50 2T LC 2006-> (C451M) (IT IS ADVISED TO USE crankshaft 53 7600)
• GILERA RUNNER 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO NRG Power 50 2T LC euro 4 2018->2020 (CA71M) (IT IS ADVISED TO USE crankshaft 53 7600 - For the proper installation of the cylinder kit it is necessary to fit the temperature sensor ADAPTER, art. 1518132B)
• PIAGGIO NRG EXTREME 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO NRG MC2 50 2T LC <-1997 (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO NRG MC2 50 2T LC 1998-> (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO NRG 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO NRG MC3 DD 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO NTT 50 2T LC (for CROSS model - IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO NRG Power DD 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO QUARTZ 50 2T LC (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO ZIP SP 50 2T LC 2001-> (IT IS ADVISED TO USE crankshaft 53 7600)
• PIAGGIO ZIP SP 50 2T LC <-2000 (IT IS ADVISED TO USE crankshaft 53 7600)
