TECHNICAL FEATURES
Cylinder
- Material: primary aluminium alloy with a high content of hardened and tempered silicon, cylinder liner with silicon carbide coating in a galvanic nickel die and crossed smoothing with two diamond passages with very limited tolerances.
- Machining: on machine tools with high precision numerical control.
- Cylinder-piston connection with an allowance of 0.05 mm.
- Recalculated and upgraded heat exchange surfaces.
Piston
- Ultra compact with 3 rings.
- Material: special aluminium alloy with high silicon content, low thermal expansion and a tin facing on the sliding surfaces.
- Machining on machine tools with numerical control.
- Lightened and reinforced.
- Upgraded heat exchange surfaces.
Piston rings
- Compression - special rings with high sliding ease and very high mechanical resistance, in chromium-plated S10 spheroidal cast-iron.
- 1st scraper - ring in chromium-plated S10 spheroidal cast iron.
- 2nd three - piece scraper ring made of chromium-plated steel alloy.
To be installed exclusively with Force Master 2 5514235
MBK EVOLIS 250 ie 4T LC 2014->
YAMAHA X CITY 250 ie 4T LC euro 3 (G358E)
YAMAHA X CITY 250 ie 4T LC euro 3 2014-> (MD42M)
YAMAHA X MAX 250 ie 4T LC euro 3 2008->2009 (G362E)
YAMAHA X MAX 250 ie 4T LC euro 3 2010->2013 (G3B7E)
YAMAHA X MAX 250 ie 4T LC euro 3 2014->2017 (G3B3E)
Modellek:
- APRILIA LEONARDO 250 4T LC
- APRILIA LEONARDO 300 4T LC
- BENELLI VELVET 250 4T LC
- ITALJET JUPITER 250 4T LC
- MALAGUTI MADISON 250 4T LC (YAMAHA)
- MALAGUTI PassWord CK 250 4T LC
- MBK EVOLIS 250 ie 4T LC 2014-> (ATTENTION : To be installed exclusively with FORCE MASTER 2 control unit art. 5514235)
- MBK KILIBRE 300 4T LC (H314E)
- MBK SKYLINER 250 4T LC
- YAMAHA MAJESTY 250 4T LC
- YAMAHA VERSITY XC 300 4T LC (H314E)
- YAMAHA X CITY 250 ie 4T LC euro 3 (G358E) (ATTENTION : To be installed exclusively with FORCE MASTER 2 control unit art. 5514235)
- YAMAHA X CITY 250 ie 4T LC euro 3 2014-> (G3B7E) (ATTENTION : To be installed exclusively with FORCE MASTER 2 control unit art. 5514235)
- YAMAHA X MAX 250 ie 4T LC euro 3 2010->2013 (G389E) (ATTENTION : To be installed exclusively with FORCE MASTER 2 control unit art. 5514235)
- YAMAHA X MAX 250 ie 4T LC euro 3 2014->2017 (G3B3E) (ATTENTION : To be installed exclusively with FORCE MASTER 2 control unit art. 5514235)
- YAMAHA X MAX 250 ie 4T LC euro 3 2008->2009 (G362E) (ATTENTION : To be installed exclusively with FORCE MASTER 2 control unit art. 5514235)
- YAMAHA X MAX 250 4T LC
