Besides its improved fuel curves, efforts from Malossi’s technical staff resulted with a rev limiter increase of 1.700 RPM depending on the vehicle, making Force Master an even higher performing ECU!
Force Master allows to change the injection in order to fit perfectly the Malossi 4-stroke and original cylinders.
- Carburation adjusting
- ± 6% at min/medium/max
- RPM limiter : + 1.700 RPM
Original 8.800 - Malossi 10.500 - (*) 3 different maps :
- curve 1 : original exhaust system, original cylinder, Malossi manifold, original head, original camshaft and original filter
- curve 2 : original exhaust system, Malossi cylinder, Malossi manifold, original head, original camshaft and original filter
- curve 3 : Malossi exhaust system, Malossi cylinder, Malossi manifold, original head, original camshaft and original filter
(*) The cdi can be installed also with the original cylinder.
Full carburetion control is achieved by combining the O2 controller with the Force Master control unit. The synergy of these two devices has no limits, the entire quoted plane is managed, controlled and optimised for any processing step proposed by Malossi.
Modellek:
- MBK NITRO 50 ie 4T LC euro 2 (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
- MBK OVETTO UBS 50 ie 4T LC euro 2 (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
- YAMAHA AEROX 4 50 ie 4T LC euro 2 (A326E) (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
- YAMAHA C3 [XF] 50 ie 4T LC euro 2 (A311E) (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
- YAMAHA GIGGLE [XF] 50 ie 4T LC euro 2 (A311E) (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
- YAMAHA NEO'S 4 50 ie 4T LC euro 2 (A316E) (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
- YAMAHA VOX [XF] 50 ie 4T LC euro 2 (A311E) (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
- YAMAHA ZUMA FX 50 ie 4T LC (ATTENTION : To be assembled EXCLUSIVELY with Malossi CYLINDER art. 3113579)
