ELECTRONIC COILS
The continuous development of electronics in the automotive segment led Malossi to the creation and marketing of a complete line of electronic coils for scooters to be used on the street and for races which is at the highest level of technology.
Each electronic coil model was expressly studied for the scooter it will be fitted on, and this is the reason why after endless tests on the bench, on rollers and on the racing track an optimal start up map (fixed or variable) has been prepared in order to obtain the best performances of the vehicle. The Malossi electronic coils were designed to allow also a very easy assembling, since they are interchangeable with the original boxes. They are compact and ergonomic, so they can be connected perfectly to the original connectors.
Furthermore, these coils allow the elimination of the rpm limiter installed on some standard power boxes, enabling in this way the full exploitation of the engine's power and torque even at the highest regimes, up to 20.000 rpm. These electronic coils are based on capacitive discharges, therefore they allow maximum limitation of circuit transients during voltage discharge, while obtaining a virtually perfect peak voltage on the spark plug (35.000 - 50.000 volts depending on the engine regime); moreover they grant extremely high discharge voltages and currents with surprising steadiness with respect to engine rpm variation.
Technical features
- Feeding of the electronic coil: original
- Maximum number of revolutions/minute: 20.000
- Voltage discharge: 35.000 – 50.000 volt
- Advance: fixed
Modellek:
- HONDA AERO NB 50 2T 1987 (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- HONDA DIO SR 50 2T (AF18E) (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- HONDA VISION 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- HONDA VISION MET IN 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- HONDA XRM 100 4T (XRM 110ME) (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- HSC SC 01 50 (AF18E) (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT BUXY 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT ELYSEO 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT JET FORCE C-TECH 50 2T LC (NOT to be used on VEHICLE WITH Dellorto ORIGINAL CONTROLLER - ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT LOOXOR 50 2T
- PEUGEOT LUDIX BLASTER 50 2T LC (HL 2) (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT METAL-X 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT RAPIDO 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT BUXY RS 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT SPEEDFIGHT 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT SPEEDFIGHT 50 2T LC (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT SPEEDAKE 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT SQUAB 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT ST 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT SV GEO 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT TREKKER 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT VIVACITY 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT X-FIGHT 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT X-FIGHT 50 2T LC (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
- PEUGEOT ZENITH 50 2T (ONLY FOR vehicles WITHOUT IMMOBILIZER KEY)
